2017 GMC Sierra 2500HD Double Cab - Specs, Features, 0-60 and Top Speed

2017 GMC Sierra 2500HD Double Cab Front View

2017 GMC Sierra 2500HD Double Cab

MSRP$39,320

Specs

  • origin countryUnited States
  • engine6 L
  • horsepower360 hp @ 5400 rpm
  • torque380 lb.-ft. @ 4200 rpm
  • transmission6-Speed Automatic
  • 0-60 time7.3 sec
  • combined fuel economy26 mpg

Trims

performance

zero to 60 mph7.3 sec
top speed162 mph

engines

valvetrainOverhead Valves (OHV)
transmission6-Speed Automatic
engine typeV8
compression ratio9.40 to 1
valves32
engine displacement366 cu.in.
engine bore x stroke4.0 x 3.6
engine size6 L
engine horsepower360 hp @ 5400 rpm
engine torque380 lb.-ft. @ 4200 rpm
engine orientationlongitudinal
engine oil cooler1
valve timing1
cylinder headAluminum
vehicle emissionLow Emission Vehicle II

MPGs

fuel economy city25 mpg
fuel economy highway26 mpg
fuel economy combined26 mpg
fuel tank capacity36 gal.
fuel typeFlex-Fuel Unleaded

interiors

cargo capacity all seats in place76.3 cu.ft.
front headroom42.8 in.
front hiproom60.73 in.
front legroom45.27 in.
front shoulder room64.84 in.
interior cargo length to rear seat22.7 in.
cargo capacity all seats folded16.4 cu.ft.
maximum cargo capacity76.3 cu.ft.
bed length98 cu.ft.
passenger capacity6
passenger volume107 cu.ft.
2nd row headroom38.67 in.
2nd row hiproom60.23 in.
2nd row legroom34.63 in.
2nd row shoulder room64.33 in.
cargo capacity 2nd row seats folded53.6 cu.ft.
cargo capacity 3rd row seats folded22.7 cu.ft.

exterior dimensions

axle ratio4.1
cab to axle55.24 in.
curb weight6489 lbs.
front axle capacity4800 lbs.
front gawr4800 lbs.
front spring rating4800 lbs.
front tire/wheel capacity5200 lbs.
front tread69 in.
gross weight9500 lbs.
ground clearance9.5 in.
height77.83 in.
length248.9 in.
payload2987 lbs.
pickup bed depth97.8 in.
rear axle capacity6200 lbs.
rear gawr6200 lbs.
rear spring rating6200 lbs.
rear tire/wheel capacity6200 lbs.
rear tread67.3 in.
turning radius26.55 in.
wheelbase158.1 in.
width80.51 in.
frame typeHydroformed

towing

maximum towing capacity14500 lbs.
5th wheel towing capacity14100 lbs.
tow hooks2 Front
trailering classClass IV Trailering With Harness, Hitch(Optional)
fixed tow barNo
tow hitchTrailer Hitch(Optional)

brake

brake assistYes
brake dryingNo
electronic brakeforce distributionNo
abs and driveline traction control4-Wheel ABS
abs channels4
power regenerationNo
front brakeIntegrated Trailer Brake Controller
rear brakeIntegrated Trailer Brake Controller
rear brake rotor diam x thickness14.17
front brake rotor diam x thickness13.98

transmission

drivetrainFour Wheel Drive
locking hubsAutomatic
overdriveYes
rear differentialLocking Differential
standard transmission6-Speed Automatic
transmission electronic controlYes
transmission oil coolerYes
paddle shiftersNo

warranty

basic warranty3 yr. / 36000 mi.
drivetrain warranty5 yr. / 60000 mi.
roadside assistanceYes
roadside warranty5 yr. / 60000 mi.
free maintenance2 yr. / 24000 mi.
rust warranty6 yr. / 100000 mi.
corrosion perforation warranty6 yr. / 100000 mi.
diesel engine warranty5 yr. / 100000 mi.
