2010 Ford Ranger SuperCab - Specs, Features, 0-60 and Top Speed
2010 Ford Ranger SuperCab
MSRP$22,155
Specs
- origin countryUnited States
- engine4 L
- horsepower207 hp @ 5250 rpm
- torque238 lb.-ft. @ 3000 rpm
- transmission5-Speed Manual
- 0-60 time7.6 sec
- combined fuel economy17 mpg
Trims
performance
| zero to 60 mph | 7.6 sec |
| top speed | 110 mph |
engines
| valvetrain | Single Overhead Cam (SOHC) |
| engine cylinder | 6cyl |
| transmission | 5-Speed Manual |
| engine type | V6 |
| valves | 24 |
| engine displacement | 245 cu.in. |
| engine size | 4 L |
| engine horsepower | 207 hp @ 5250 rpm |
| engine torque | 238 lb.-ft. @ 3000 rpm |
MPGs
| fuel economy city | 15 mpg |
| fuel economy highway | 21 mpg |
| fuel economy combined | 17 mpg |
| fuel tank capacity | 19.5 gal. |
| range in miles | 292.5/409.5 mi. |
| fuel type | Regular Unleaded |
interiors
| cargo capacity all seats in place | 25.3 cu.ft. |
| front headroom | 39.2 in. |
| front hiproom | 52.7 in. |
| front legroom | 42.4 in. |
| front shoulder room | 54.5 in. |
| cargo capacity all seats folded | 37.4 cu.ft. |
| maximum cargo capacity | 37.4 cu.ft. |
| bed length | 73 cu.ft. |
| passenger capacity | 4 |
| 2nd row headroom | 33.2 in. |
| 2nd row hiproom | 18.7 in. |
| 2nd row legroom | 39.1 in. |
| 2nd row shoulder room | 14.1 in. |
exterior dimensions
| angle of approach | 23.8 degrees |
| angle of departure | 24.3 degrees |
| cab to axle | 38 in. |
| curb weight | 3718 lbs. |
| front axle capacity | 2850 lbs. |
| front gawr | 2710 lbs. |
| front spring rating | 2710 lbs. |
| front tire/wheel capacity | 1843 lbs. |
| front tread | 58.5 in. |
| gross weight | 5000 lbs. |
| ground clearance | 8 in. |
| height | 66.3 in. |
| length | 203.6 in. |
| payload | 1100 lbs. |
| pickup bed depth | 72.7 in. |
| rear axle capacity | 2750 lbs. |
| rear gawr | 2600 lbs. |
| rear spring rating | 2600 lbs. |
| rear tire/wheel capacity | 1843 lbs. |
| rear tread | 57.3 in. |
| turning radius | 21.35 in. |
| wheelbase | 125.7 in. |
| width | 69.4 in. |
| frame type | Ladder |
towing
| maximum towing capacity | 5760 lbs. |
| tie down | (4) cargo box Tie-down hooks |
| fixed tow bar | No |
brake
| brake drying | No |
| electronic brakeforce distribution | Yes |
| abs and driveline traction control | 4-Wheel ABS |
| power regeneration | No |
| front brake | Ventilated Front Disc Brakes |
| rear brake | Ventilated Rear Drum Brakes |
| front brake rotor diam x thickness | 11.28 x 0.39 |
transmission
| drivetrain | Rear Wheel Drive |
| overdrive | No |
| standard transmission | 5-Speed Manual |
| transmission electronic control | No |
| transmission oil cooler | No |
| paddle shifters | No |
warranty
| basic warranty | 3 yr. / 36000 mi. |
| drivetrain warranty | 5 yr. / 60000 mi. |
| roadside assistance | Yes |
| roadside warranty | 5 yr. / 60000 mi. |
| rust warranty | 5 yr. / Unlimited mi. |
